3m™ TufQuin
Blank of 3m™ TufQuin; 0.300 mm thick, approx 420 x 594 mm, package contains 1 pc blank.
3m™ TufQuin tft 50 fi 14130 is a flexible laminate with very good dielectric stress and mechanical strength due to its construction of inorganic 3m TufQuin insulation paper and polyester film.
3m™ TufQuin tft 50 fi 14130 is halogen-free according to iec 61249-2-21 standard and certified to ul® for class n (200°C).
It offers excellent resistance to partial discharge damage, long-term dielectric strength at high temperatures, mechanical strength and thermal conductivity, and good dielectric strength.
In addition, 3m™ TufQuin tft 50 fi 14130 has high moisture resistance and excellent impregnant absorption capacity.
3m™ TufQuin tft 50 fi 14130 is used, for example, for motors, coils and electromagnets.
3m™ TufQuin tft 50 fi 14130 is suitable for use in electrical insulation systems (eis) according to ul® 1446 and iec 61857.
In the ul database, these papers are listed under file number e65069 as well as e65007.
3m™ TufQuin tft 50 fi 14130 is supplied in a white color as standard.
3m™ TufQuin tft is a registered trademark of 3m™ Co, USA.
