Polyester film PPP - FI 13095 - Configuration

Item number: FI13095-Konfiguration

Category: Polyester film - Flexiso PPP FI 13095 - Sheet configuration

0,00 €

including 19% VAT., plus shipping

Bohrungen
Preisfaktor
Breite
Länge
Available now! (Shipping time: 3 - 4 workdays)
Description

polyester film ppp - fi 13095

Individual cuts from polyester film ppp - fi 13095

Structure:

Flexiso® ppp fi 13095 is a flexible multi-layer insulation material according to iec 626-1. It is constructed in the following triple combination: Inner layer: polyester electrical insulation foil according to iec 674,

Outer layers:

highly compressed roll pressboard type p 6.1 according to iec 641-1. Flexiso® ppp fi 13095 is used as insulating material for electrical engineering up to and including insulating material class b (130°C).

Property:

Flexiso® ppp fi 13095 is well absorbent for impregnating varnishes as well as impregnating and trickling resins of all insulation material classes due to the pressspan outer layers, thus there is an excellent connection of all winding components. Flexiso® ppp fi 13095 has a smooth surface and therefore has good machine processability.

Application:

Flexiso® ppp fi 13095 is used as slot insulation, slot closure and layer insulation (for winding head and phase insulation).

Further forms of delivery:

We also supply stamped parts made of Flexiso® ppp fi 13095 as well as moulded parts made of Flexiso® ppp fi 13095. If the desired dimension is not included, please write us a message.

Storage conditions:

Flexiso® ppp fi 13095 has a moisture content of approx. 6 % when delivered. In order to maintain this moisture content, which is necessary to maintain good workability, the material must either be stored in the undamaged original packaging or kept in a room which has a temperature of approx. 20 °C and approx. 65 % relative humidity.

Trademark information:

Flexiso® is a registered trademark of Dr. Dietrich Müller GmbH, Germany.

Characteristics
Contents:
1,00 m2
