Norton® TH FI 16011
Structure:
Norton® TH FI 16011 is a polyimide film, abbreviated PI, whose most important structural feature is the imides. The polyimides are produced by condensation polymerisation and further processed into film in a further chemical processing step.
Properties:
Norton® TH FI 16011 is a high performance plastic with a unique combination not otherwise found in polymeric film materials. This makes it ideal for a wide range of applications in numerous fields. Norton® TH FI 16011 has excellent chemical resistance; no known organic solvents.
Norton® TH FI 16011 is dimensionally stable, with a shrinkage of less than 0.08%. Furthermore, Norton® TH FI 16011 has no melting point, is flame retardant and has the highest flammability rating according to UL-94 V-0 (UL-File: E231847) and only starts to carbonise at 800°C. Thanks to its excellent properties, Norton® TH FI 16011 can be used at extremely low temperatures down to -265°C and high temperatures up to over 400°C and has a continuous temperature resistance of +220°C, at which other organic materials are no longer functional. As standard, Norton® TH FI 16011 is used at temperatures from 20 - 220 °C.
Applications:
Norton® TH FI 16011 is used as electric motor insulation, cable and conductor insulation, in windings, in solenoids, in transformers, in capacitors and in printed circuit boards. Norton® TH FI 16011 film can be laminated, metallised, die cut or adhesive coated.
Standard colour:
Norton® TH FI 16011 is supplied in the colour amber.
Other delivery forms:
We also supply moulded parts made of Norton® TH FI 16011 and punched parts made of Norton® TH FI 16011. Other dimensions and delivery forms on request.
